Description
| Wireless Transmission | |
|---|---|
| Technology | LoRaWAN® |
| Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 |
| Tx Power | 16dBm(868)/20dBm(915)/19dBm(470) |
| Sensitivity | -137dBm @300bps |
| Mode | OTAA/ABP Class A |
| Measurement | |
| Range & Accuracy | W050: 0.3 – 5 m, ±1% FS W100: 0.5 – 10 m, ±1% FS C050: 0.25 – 5 m, ± (1+0.3%*S) cm, S=distance C100: 0.25 – 8 m, ± (1+0.3%*S) cm, S=distance |
| Resolution | 1 mm |
| Operation | |
| Power On & Off | NFC, Power Button (Internal) |
| Configuration | Mobile App(via NFC) or PC software(via USB Type-C) |
| Physical Characteristics | |
| Power Supply | 19000 mAh Li-SOCL2 battery (ER34615) |
| Battery Life* | 10 years (10 min interval) |
| Operating Temperature | W050/W100: -30°C to +65°C C050/C100: -15°C to +60°C |
| Relative Humidity | 0% to 80% (non-condensing) |
| Ingress Protection | IP67 |
| Dimension | 156.1 × 71 × 69.5 mm (6.1 × 2.8 × 2.7 in) |
| Installation | Pole, wall or DIN Rail Mounting |
| Approvals | |
| Regulatory | CE, FCC, RoHS, LoRaWAN® Certified |
| EMC | EN 55032, EN 55035 |
| EMS | IEC 61000-4-2 Level 3, IEC 61000-4-3 Level 2, IEC 61000-4-8 Level 4 |
| Radio Frequency | FCC Part 15B, FCC Part 15.247, EN 300 330, EN 301 489-1/3, EN 300 220-1/2 |
| Safety | EN62368-1 |
* Tested under laboratory conditions and for guideline purposes only.
